• Film/ Coating Thickness Gauge possesses the following features:



  1.Providing visual readings and status of measurement
  on LCD
  2.Applying high sensitivity sensor for precise measurement
  3.With zero-point, two-points, and basic calibration methods
  to amend the system error quickly;
  4.With single, continuous and compensation measuring
  methods;
  5.Capable of saving, reviewing and deleting the data
  6.Able to delete the unreliable data in a measuring process
  as well as the data all saved in unit
  7.To save the maximum value, minimum value, average
  value, standard compensation value and measuring times
  8.Buzzer alert
  9.Unit switch between the metric and Britain system;
  10.Low battery indication
  11.Automatically turning off
  12.LCD backlight


• Technical parameter	Technical index
  LCD display	3 1 / 2 display
  Power supply	3*1.5V AAA alkaline battery
  Operation current	Around 25mA
  Battery life	Continuously 20 hour
  Auto off	1 min.
  LCD backlight function	7 second
  Operation temperature	0 to 40℃
  Operation humidity	10 to 95%RH
  Low battery indication	2.8V±0.2V
  Product size	72x35x145mm
  Weight	246.1g (without battery)



• Please refer to the manual for details
• Digital coating thickness tester main unit*1
  Sensor*1
  1.5V AAA battery*3
  English Instruction Manual*1
  Standard sheet*6
  Iron base material for calibration*1
  PP Packing Box*1

•
•
